Classic 615
Double sliding doors with soft closing mechanism
The sliding double door glass wall consists of two sliding door panels and a sliding mechanism mounted to the building wall above the doorway. Sliding door fixture takes up very little space in the room, a quality sliding mechanism and a floor guide fitting provides a smooth and safe door movement. The doors are equipped with soft closing mechanism which cushions the closing and gently pulls the door into position.
The sliding rail profile is fixed to the wall(ceiling). The sliding
mechanism is affixed to the top of the door panel before being mounted on
the sliding profile. A door guide is installed on the floor. The sliding
rail profile is covered from the front and sides with cover plates.
Installation services are available in Finland capital (Helsinki, Espoo, Vantaa, Kauniainen, Porvoo, Sipoo, Kirkkonummi, Nurmijärvi, Kerava, Järvenpää, Riihimäki, Pornainen, Hyvinkää, Tuusula), Tampere (Tampere, Nokia, Kangasala, Lempäälä ja Pirkkala), Häneemlinna and Lahti (Lahti, Mäntsälä, Orimattila) regions. Service is carried out by manufacturers professional mechanic. When product is ordered with installation service, transport company delivers the product to customer site. When the product has arrived, mechanic will phone customer and agree the exact installation date and time. Installation is done to clean and installation ready surfaces. Installation work includes besides installation of the product also taking away the installation garbage. If you are unsure about the measures of the product (for example in case of custom sized products), you can order a measurement visit on-site done by the mechanic. In this case the mechanic will fill-in the final measures of the product to the system and the responsibility that measures are correct is carried by the manufacturer.
17 Working days
5 year warranty
The black (RAL 9005) option is painted through powder coating, and the grey option - through anodized coatings.
The product is manufactured of 8mm thick tempered safety panel (EN 12150). One side of the satin panel is etched to acquire a velvety feel and the other side is smooth. When choosing a satin panel product, bear in mind that the etched surface of the panel is sensitive to scratches and stains.
Glass wall is manufactured according to custom dimensions.
Product size
:
The round handle is manufactured from brushed brass alloy. The polished hole handle consists of a polished edge round cutout in the door glass. Handle height is 0.5B (as per 2D drawing).
Product
Product code
Price
1
Classic 615
Product code
615-81-00
Price
0.00 €
2
Classic 615 wall mounted, A
Aluminium/Transparent=650 x 2000
Product code
615 81 0000
Price
675.00 €
3
Classic 615 wall mounted, B
Aluminium/Transparent=650 x 2000
Product code
279 81 0000
Price
675.00 €
4
TOTAL
Product code
Price
1350.00 €
:
